CPAP,bubble,newborn,w/compressor & SpO2

Product Code : SCL-MAI-12345
GENERAL DESCRIPTION
Continuous Positive Airway Pressure (Bubble CPAP) system for the non-invasive respiratory support of normal, premature or low-birth weight neonate with spontaneous breathing. The unit has an integrated pulseoximeter to measure the level of arterial oxygen saturation in blood.

IMPORTANT
Training and installation are not included with the device and must be requested separately from the supplier or manufacturer. Improper operation or maintenance can result in harm to patients and/or operators, including death. Therefore, UNICEF strongly recommends the inclusion of installation and training services for both operators and technicians, unless identical models of these devices are already in use at the intended installation site. Neither UNICEF nor the manufacturer can assume responsibility for any consequences arising from incorrect operation and/or maintenance. Training and installation will have to be quoted separately; the number of operators and technicians to be trained, and the locations where these trainings will have to take place, are required in order to obtain a quotation.

INTENDED USE
An electrically-powered device designed to deliver high-flow (exceeding peak inspiratory flow) heated and humidified ambient air or air/oxygen to a neonatal patient as part of noninvasive ventilation (NIV); it may additionally be used with a water tank to produce bubble continuous positive airway pressure (bubble CPAP). It consists of a gas flow generator that entrains room air, an oxygen input, a heating element, and humidification chamber; it does not include CPAP controlling pressure sensors (i.e., not a full CPAP unit). It is intended for use by a healthcare provider on a spontaneously breathing patient in hospital settings.

TECHNICAL SPECIFICATIONS
The unit supports bubble CPAP Mode.
Specifically for support of neonates and newborns.
The unit has an integrated air compressor.
The pressure/flow of the CPAP generator is regulated electronically.
The unit has an integrated humidifier.
The unit is equipped with an electronic air/oxygen mixer.
The unit has an integrated FiO? analyser.
The unit accepts inlet gas supply pressures between 1.7 – 4.1 bar (25 to 60 psi).
DISS O? connection. (Other type connectors available indicate when ordering).
Supplied with pole mounting system, wheeled and with brakes.
The pole mounting system is equipped with 4 antistatic swivel castors, of which two castors. have been equipped with brakes.
Equipped with an air filter and a water trap.
Suitable for heated and non-heated closed patient circuits.
The unit accepts other than the manufacturer patient circuits.
All components of the system (single-use filters and patient circuits excluded) are suitable for disinfection with hospital grade products.
CPAP pressure range adjustable from 0 to 10 cm H2O.
Maintains constant CPAP at outlet.
A minimum output flow range adjustable between: 4 – 9 L/min.
Oxygen concentration adjustable between: 21 - 100 %.
Pressure indicator in cmH2O.
Noise emission less than 50 dB.
Including a clamp for a rail and/or pole.
External electric heating and humidifying chamber.
Relative humidity output up to 100%.
Adjustable output temperature up to 36°C.
Power requirements: 100 - 240 Volts - 50/60 Hz (not necessarily in a single unit).

ALARMS
Alarms are audible as well as visual.
The unit has alarms for the following:
- High temperature.
- System failure.
- High/low oxygen concentration (FiO?).
- High airway pressure.
- Failure in either air or oxygen supply.
- Mains power failure.
- Low battery.

SAFETY PROVISIONS
Overheating protection.
The unit is equipped with a rechargeable battery which provides for a minimum of 1 hour autonomous operation.
In case of power failure the unit switches automatically to battery power.
The unit automatic recharges on reconnection to mains.

INTEGRATED PULSEOXIMETER
The unit is equipped with an integrated pulseoximeter.
Saturation accuracy between 70% and 100% is ±3%.
Measurement range SpO?: 1% to 100% saturation .
Perfusion index: 0.02% to 20%.
Pulse rate range: 25 to 240 bpm.
Pluse rate accuracy is ±5%.

SUPPLIED WITH
Instructions for assembly, use and maintenance in English.
1 x Plastic protective dustcover.
4 x reusable patient circuits.
2 sets of extra small size reusable CPAP head bonnets.
2 sets of small size reusable CPAP head bonnets.
2 sets of medium size reusable CPAP head bonnets.
10 x nasal cannulas, soft and atraumatic, for premature neonates.
10 x nasal cannulas, soft and atraumatic, for term neonates and older infants.
1 x set of hoses for connecting external oxygen and medical air supply, length > 2 m.

ESTIMATED LIFE SPAN
7 years.

WARRANTY
Two years from shipping date.

ENVIRONMENTAL CONDITIONS
- Operating conditions: 19°C - 37°C / 30% – 90% RH.
- Storage conditions: 10°C - 65°C / 5% – 90% RH.
- Atmospheric pressure: 700 ~ 1060hPa.
- Ingress protection rating: IPX1.

WEIGHT AND VOLUME (packaged).
Weight: 28 kg.
Volume: 202 dm³.
