FHR monitor, continuous, portable
.png)
Product Code : SCL-MAI-12255
GENERAL DESCRIPTION
Portable, handheld, foetal heart rate monitor
INTENDED USE
A portable, hand-held, battery-powered device assembly consisting of a measuring and display unit and an attached probe or interchangeable probes designed to noninvasively detect foetal heart beats using ultrasound/Doppler technology. The heart beats are typically conveyed audibly via the measuring/display unit and attached probe which is applied to the surface of the pregnant woman's abdomen. The device aids in determining foetal viability.
TECHNICAL SPECIFICATION
Device for non-invasive detection of foetal heart rates, either continuous or intermittent.
Portable, battery operated.
Suitable to be used for ambulatory patients.
Including ultrasound probe.
Designed with a wide detection area thus making positioning of the probe less critical and making the device less sensitive to movement of the mother.
Capable of detecting foetal heart rates between 50 - 210 bpm, with an accuracy of ± 5 bpm between 50 - 200 bpm.
Capable to measure maternal heart rates between 30 - 250 bpm, with an accuracy of ± 5 bpm between 50 - 150 bmp.
Contains a built-in speaker which can convey the foetal heart rate audible or be switched off.
Including display indicating the foetal and maternal heart rates.
Memory allowing for storage of 30 minutes foetal heart rate trend.
Rechargeable battery with a minimum capacity for 5 hours continuously monitoring.
Battery charger suitable for 100 - 240 volt / 50 - 60Hz.
Suitable for cleaning with hospital grade products
ALARM FUNCTIONALITIES
Alarms are visual and audible
Alarms can be silenced
Alarm when the foetal heart rate cannot be detected, indicate applicable ranges:
Alarms for low and high foetal heart rates, indicate applicable ranges
Alarm for low battery
SUPPLIED WITH
Instructions for assembly, use and maintenance in English, French and Spanish.
1 x Pouch or container to store the device and its components.
1 x Adjustable strap to position the probe around the belly of the mother
1 x Battery charger
ESTIMATED LIFE SPAN
The estimated life span is 3 – 5 years
WARRANTY
Warranty period is two (2) years including supplied accessories.
ENVIRONMENTAL CONDITIONS
Storage conditions: -30 - 70°C / 95% relative humidity.
Operating conditions: 0 - 40°C / 95% relative humidity.
Atmospheric pressure: 800hPa to 1060hPa (Storage: 550hPa to 1060hPa)
Ingress Protection rating: IP41
WEIGHT AND VOLUME (packaged)
Weight: 1.15 kg.
Volume: 4.33 dm³
ESTIMATED DELIVERY LEAD TIME
28 days.
