Resuscitator,hand-oper.,neonate,set
.png)
Product Code : SCL-MAI-12308
GENERAL DESCRIPTION
Resuscitator intended for full-term babies, preterm and low-weight infants up to 7 kg.
INTENDED USE
Resuscitators are used for ventilation assistance in critical situations of respiratory distress or failure. It is considered essential equipment for health structures and emergency rescue team (to be available in emergency room, delivery room, operating theatre, intensive care unit, ambulance, etc.).
TECHNICAL SPECIFICATIONS
Hand-operated in a horizontal position.
Portable, self-inflating and reusable
The resuscitator is autoclavable between 121°C and 134°C.
The capacity of the self-inflating ventilation bag is between 250 - 280ml.
Ventilation can be done with ambient air or with oxygen.
The resuscitator has an inlet valve with a nipple for oxygen tubing.
The resuscitator is equipped with a non-rebreather valve.
Resuscitator can be fully disassembled, is easy to clean, disinfect, and reassemble.
The resuscitator is equipped with a pressure release (limiting) valve which safeguards against generating ventilation pressures over 45 cmH?O, while still allowing for airway pressures up to at least 30 cmH?O.
The pressure release valve is equipped with a feature allowing it to be overridden by the user when higher pressures need to be generated in the airways.
When the pressure release valve is not overridden by the user, it should either automatically return to its default position whereby it protects against excess pressures or be clearly visible so there is no doubt as to its closed position, even during an emergency. To ensure users are fully aware that the limiting valve is in closed position.
All parts are manufactured from high-strength, long-life materials that require no special maintenance or storage conditions.
SUPPLIED WITH
Instructions for assembly, use and maintenance in English, French and Spanish.
1 x Plastic protective pouch which can contain the full set
1 x Mask, transparent: size 0 for preterm and low-weight baby, round type, diameter 35–50 mm
1 x Mask transparent: size 1 for term baby, round type, diameter 50–65 mm
1 x Oxygen reservoir bag with an appropriate capacity
1 x Required tubing and other accessories to connect to oxygen supply
LIFE SPAN
The life span of the device is minimum 3 years or 20 autoclave sessions, whichever comes first.
EXPIRY DATE
This product has a minimum total shelf life of 5 years.
WARRANTY
Two years from shipping date
ENVIRONMENTAL CONDITIONS
- Operating conditions: -18°C - 45°C / 15% – 90% RH
- Storage conditions: -30°C - 50°C / 40% – 90% RH
WEIGHT AND VOLUME
Weight: 0.5 kg
Volume: 4.056 dm3
ESTIMATED DELIVERY LEAD TIME
90 days
