Oxygen concentrator, 10 LPM, single flow

Product Code : SCL-MAI-12404
GENERAL DESCRIPTION
A mains electricity powered device that concentrates oxygen from ambient air and delivers the concentrated oxygen in a controlled manner to a patient requiring oxygen therapy via a single outlet up to 10 L/min.

IMPORTANT INFORMATION
Oxygen concentrators are not suitable to be used as an oxygen source to other medical equipment providing respiratory support, such as ventilators, CPAP devices, High Flow Nasal Oxygen, etc.

TECHNICAL SPECIFICATIONS
Features:
Provides a continuous, variable flow of concentrated oxygen 93 ± 3% derived from room air.
Contains oxygen sensor to verify concentration.
Equipped with a single oxygen outlet, with a controllable flowmeter.
Continuous flow to a maximum rate of 10L/min.
Minimum deliverable flow rate of 0.5 L/min.
Flowmeter continuously adjustable, with markings at 0.5 L/min intervals.
Outlet pressure: 0.04 – 0.07 MPa (5.8 – 10.2 PSI).
Power efficiency ≤ 70 W/L/min.
Noise level < 60 dB(A).

Display:
User interface easy to operate; numbers and displays clearly visible and easily readable in low ambient light and sunlight.
Digital meter that displays cumulative hours of device operation.

Alarms:
Audible and visual alarms for low oxygen concentration (< 85%).
Audible and visual alarms for power supply failure.
Audible and visual alarms for high temperature.
Audible and visual alarms for low and high pressure.
Audible and visual low flow alarm; when the nasal cannula is bent or blocked, and the flow is below 0.5 L/min, then the low flow alarm is triggered.
Audible and visual over flow alarm; when the flow reading is greater than 10 L/min, then the over flow alarm is triggered.

Casing and environment:
Hard case, cleanable according to manufacturer’s instructions.
Oxygen outlet securely mounted and sheltered to reduce risk of being broken or bent.
The unit includes internally and externally mounted filters for cleaning the air intake.
All user-removable filters are cleanable. Cleaning instructions for filters are included in the instructions for use.
Whole unit movable with wheels on at least two castors.
Unit weight ≤ 27 kg.

Electrical characteristics:
Mains power cable length ≥ 2.5m.
Voltage: 230V, Frequency: 50/60Hz.
Capacity for safe operation from at least ± 10% of rated voltage.
Electrical protection by resettable circuit breakers or replaceable fuses, fitted in both neutral and live lines.

SUPPLIED WITH
4 x adult nasal cannulas with 2m kink-resistant oxygen tubing with standard connectors.
4 x paediatric nasal cannulas with 2m kink-resistant oxygen tubing with standard connectors.
4 x neonatal nasal cannulas with 2m kink-resistant oxygen tubing with standard connectors.
1 x reusable humidifier bottle.
1 x DISS to 6mm barbed adaptor (for connection from oxygen concentrator outlet to oxygen tubing).
Internal and external filters for user fitting, as described in user manual, for 2 years' operation at 15 hours per day (in addition to those already included within the unit):
-- 6 x gross particle filter
-- 6 x inlet filter
-- 1 x bacterial filter
2 x sets of spare fuses.
1 x set user and maintenance manuals in English, French and Spanish. If compete manuals are only available digitally, a quick reference guide and information sheet which clearly indicates the url to access complete manuals must be included with the device.
1 x certificate of calibration and inspection.
1 x list of all equipment and procedures required for routine maintenance (in manual).
1 x list of all spares and accessories, with part numbers and contact details for parts supply.
1 x document with contact details of manufacturer, supplier and local service agent.

ITEMS RECOMMENDED, BUT NOT SUPPLIED
Filter set (see Related Products)
Spare part kit (see Related Products)

SHELF LIFE
5 years

ESTIMATED LIFE SPAN
5 years at minimum.
Supplier commits to the availability of spare parts & consumables for the above indicated life span.

WARRANTY
Includes 2-year standard warranty, dated from the completion of the terms of delivery.

ENVIRONMENTAL CONDITIONS
Capable of being stored continuously in ambient temperature of -40°C to 55°C, relative humidity ≤ 95%.
Continuous operation within specification in ambient temperature of 5°C to 40°C, relative humidity 15 to 93% and altitude of up to 2286m.
IP21 ingress protection.

WEIGHT/VOLUME (Packaged)
Weight: 30kg
Volume: 0.132m³
