Oxygen Analyzer, ultrasonic, handheld

Product Code : SCL-MAI-12412
GENERAL DESCRIPTION
Hand held, battery powered device that measures the oxygen concentration in a flow of gas from a medical gas source or, with adapters, through a medical gas-flow device such as a ventilator or anaesthesia system. The intended application is checking gas supply equipment performance.

TECHNICAL SPECIFICATIONS
Operational Characteristics:
Ultrasonic oxygen sensing technology, with permanent sensing chamber.
O2 measurement to include the range 21 - 96%.
O2 resolution: 0.1%.
O2 accuracy: within ± 1.5% of full scale.
Flow rate measurement: up to 10 LPM
Flow rate accuracy within ± 0.2 LPM
Flow rate resolution 0.1 LPM
Suitable for measuring gas supply with pressure up to 50 psi (344 kPa)
Response time < 20 s.
Warm-up time < 1 s.
Display visualizing O2 concentration, flow rate, system messages and battery status.

Electrical characteristics:
Operated by 2 x AA alkaline replaceable single use batteries.
Battery life > 1000 hours continuous use.
Automatic power-off when not in use.

Casing and environment
IPX1 ingress protection.
Suitable for cleaning and disinfection with hospital-grade cleaning products.

SUPPLIED WITH
1 x protective case
Connector tube for gas sampling
1 x set single use batteries (2 AA batteries)
1 x Instructions for Use, hard and soft copies in English, French, Spanish, German, Dutch and Italian.
1 x Contact details of manufacturer.

ENVIRONMENTAL CONDITIONS
Capable of being stored continuously in ambient temperature from -15°C to 60°C, RH: 0 to 95%
Capable of operating continuously in ambient temperature from 15°C to 40°C, RH: 0 to 95%

WARRANTY
24 months
